Diameter mm | Φ 50.8 - 125 < Φ 50.8 upon special request > Φ 125 upon special request | ||||
|---|---|---|---|---|---|
| Type | Orientation | Resistiity Range Ωcm | Tolernace (min) % | RV (max) % | Lifetime (min.) μs |
N N |
<111> <111> |
1 ~ 100 100 ~ 1,000 |
± 18 ± 20 |
30 30 |
200 1000 |
N N |
<100> <100> |
1 ~ 100 100 ~ 1,000 |
± 15 ± 20 |
15 17 |
200 1000 |
P P |
<111> <111> |
1 ~ 100 100 ~ 1,000 |
± 20/12 ± 25/15 |
12 15 |
100 200 |
P P |
<100> <100> |
1 ~ 100 100 ~ 1,000 |
± 20/12 ± 25/12 |
12 15 |
100 200 |
